Feature
●Compliant with IEEE 802.3bz&802.3at standard.
●Comply with RoHS requirements.
●Suitable for End-span PoE applications with 720mA current capability.
●Operating temperature range: 0℃ to +70℃.
●Storage temperature range: -25℃ to +105℃.
Electrical Specifications @ 25℃
|
OCL: |
150uH Min. @100KHz/0.1V with 10.8mA DC Bias |
|||
|
Hi-POT : |
1500Vrms |
|||
|
Turn Ratio: |
1CT:1CT±3% |
|||
|
D.C.R: |
1.0 ohm Max |
|||
|
Insertion Loss: |
-1.0dB Max@1-100MHz |
|||
|
-1.8dB Max@100-250MHz |
||||
|
Return Loss: |
@1-40MHz |
@40-100MHz |
@100-125MHz |
@125-250MHz |
|
-18dB Min |
-12dB Min |
-11dB Min |
-9dB Min |
|
|
Cross Talk : |
@30MHz |
@100MHz |
@250MHz |
|
|
-35dB Min |
-30dB Min |
-28dB Min |
||
|
DCMR: |
@30MHz |
@100MHz |
@250MHz |
|
|
-35dB Min |
-30dB Min |
-25dB Min |
||
