Feature
●Compliant with IEEE 802.3an&802.3bt standard.
●Comply with RoHS requirements.
●Designed to support applications up to 1080mA Per centre tap
●Operating temperature range: -40℃ to +125℃（90℃ MAX，AMBIENT+35℃ TEMP,RISE）
●Storage temperature range: -40℃ to +125℃.
Electrical Specifications @ 25℃
|
OCL: |
120uH Min. @100KHz/0.1V,with 15mA DC Bias(-40℃to +125℃) |
|
Hi-POT : |
1500Vrms |
|
Turn Ratio: |
1CT:1CT±3% |
|
D.C.R: |
1.0 ohm Max |
|
Insertion Loss: |
-3.0dB Max @100KHz |
|
-2.0dB Max @1-400MHz |
|
|
-3.0dB Max @500MHz |
|
|
Return Loss: |
-18dB Min @1-40MHz |
|
-17+10log(f/40)dB Min @40-500MHz |
|
|
Cross Talk : |
-40dB Min @1-100MHz |
|
-30dB Min @100-500MHz |
|
|
CMRR: |
-30dB Min @1-250MHz |
|
-22dB Min @250-500MHz |
