Feature
●Compliant with IEEE 802.3ab standard.
●Comply with RoHS requirements.
●Operating temperature range: 0℃ to +70℃.
●Storage temperature range: -25℃ to +125℃.
Electrical Specifications @ 25℃
|
OCL: |
350uH Min. @100KHz/0.1V with 8mA DC Bias |
|||||
|
Hi-POT : |
1500Vrms |
|||||
|
Turn Ratio: |
1:1±3% |
|||||
|
LK: |
0.4uH Max @100KHz/0.2V |
|||||
|
Cw/w |
30PF Max @100KHz/0.2V |
|||||
|
D.C.R: |
1.2 ohm Max |
|||||
|
Insertion Loss: |
1-100MHz: -1.0dB Max |
|||||
|
Cross Talk : |
30MHz: |
60MHz |
100MHz |
|||
|
-45dB Min |
-40dB Min |
-35dB Min |
||||
|
Return Loss: |
1-30MHz |
40MHz |
50MHz |
60-80MHZ |
80-100MHZ |
|
|
-18dB Min |
-14.4dB Min |
-13.1dB Min |
-12dB Min |
-10dB Min |
||
