Feature
●Comply with RoHS requirements.
●Operating temperature range: -40℃ to +125℃.
●Storage temperature range: -40℃ to +125℃.
Electrical Specifications @ 25℃
OCL: |
(1-3)= 650uH Min. @100KHz/0.1V |
Hi-Pot : |
Pri to Sec: 1250VAC 0.5mA 1Sec |
Turns Ratio: |
(6-4):(1-3)= 3CT:1CT±2% |
LK: |
(1-3,shorted 6-4)= 0.6uH Max @100KHz/0.1V |
DCR: |
(1-3) : 0.8ohm Max |
(6-4): 2.0ohm Max |
