Feature
●Compliant with IEEE 802.3ab standard.
●Comply with RoHS requirements.
●Comppliant with Halogen Free requirement.
●Operating temperature range: -40 to + ℃ 125℃.
●Support LAN interface for network equipment, communication equipment, digital appliances, etc
Electrical Specifications @ 25℃
|
OCL: |
350uH Min. @100KHz/0.1V with 8mA DC Bias |
||||
|
Hi-POT : |
1500Vrms |
||||
|
Turn Ratio: |
1:1±5% |
||||
|
LK: |
0.5uH Max @100KHz/0.2V |
||||
|
Cw/w |
35pF Max @100KHz/0.2V |
||||
|
Insertion Loss: |
1-80MHz: -0.8dB Max |
||||
|
80-125MHz: -1.0dB Max |
|||||
|
Return Loss: |
1-30MHz |
40MHz |
50MHz |
60-80MHZ |
80-100MHZ |
|
-18dB Min |
-14.4dB Min |
-13.1dB Min |
-12dB Min |
-10dB Min |
|
