Feature
●Comply with RoHS requirements.
●Operating temperature range:-25℃ to +125℃.
●Storage temperature range: -25℃ to +125℃.
Electrical Specifications @ 25℃
|
OCL: |
10mH Min. @1KHz/0.25V. |
|
Turn Ratio: |
1:1±3% |
|
D.C.R: |
120mΩ Max |
|
Hi-POT : |
1500VAC 1mA 2S |
|
Insulation resistance: |
100 MΩ Min DC 500V |
