Feature
●Compliant with IEEE 802.3
●Comply with RoHS requirements.
●Designed to support applications up to 600mA Per centre tap
●Operating temperature range: 0℃ to +70℃.
●Storage temperature range: -25℃ to +105℃.
Electrical Specifications @ 25℃
|
OCL: |
120uH Min. @100KHz/0.1V, |
|
Hi-POT : |
1500Vrms |
|
Turn Ratio: |
1CT:1CT±3% |
|
Insertion Loss: |
-2.0dB Max @1-600MHz |
|
-2.5dB Max @600-800MHz |
|
|
Return Loss: |
-20dB Min @1-40MHz |
|
-20+10log(f/40)dB Min @40-600MHz |
|
|
-9+20log(f/600)dB Min @600-800MHz |
|
|
Cross Talk : |
-40dB Min @1-100MHz |
|
-25dB Min @100-600MHz |
|
|
-18dB Min @600-800MHz |
|
|
CMRR: |
-30dB Min @1-100MHz |
|
-20dB Min @100-600MHz |
|
|
-15dB Min @600-800MHz |
