Feature
●Comply with RoHS requirements.
●Comply with IEEE802.3an&802.3at.
●Suitable for End-span PoE applications with 720mA current capability
●Operating temperature range: 0℃ to +70℃.
●Storage temperature range: -25℃ to +125℃.
Electrical Specifications @ 25℃
|
OCL: |
120uH Min. @100KHz/0.1V with 10.8mA DC Bias |
|
Hi-Pot : |
1500Vrms |
|
Turns Ratio: |
1CT:1CT±3% |
|
D.C.R: |
1.0 ohm Max |
|
Insertion Loss: |
-1.5dB Max@1-250MHz |
|
-3.0dB Max@250-500MHz |
|
|
Return Loss |
-16dB Min@1-40MHz |
|
-16+10log(f/40)dB Min@40-500MHz |
|
|
Crosstalk |
-35dB Min@1-100MHz |
|
-30dB Min@100-500MHz |
|
|
CMRR |
-30dB Min@1-250MHz |
|
-20dB Min@250-500MHz |
