Feature
●Compliant with IEEE 802.3ab standard.
●Comply with RoHS requirements.
●Operating temperature range: 0℃ to +70℃.
●Storage temperature range: -25℃ to +125℃.
Electrical Specifications @ 25℃
OCL: |
350uH Min. @100KHz/0.1V with 8mA DC Bias |
||||
Hi-POT : |
1500Vrms |
||||
Turn Ratio: |
1:1±3% |
||||
LK: |
0.5uH Max @100KHz/0.2V |
||||
Cw/w |
35PF Max @100KHz/0.2V |
||||
D.C.R: |
1.2 ohm Max |
||||
Insertion Loss: |
1-100MHz: -1.0dB Max |
||||
Cross Talk : |
1-100MHz: -35dB Min |
||||
Return Loss: |
1-30MHz |
40MHz |
50MHz |
60-80MHZ |
80-100MHZ |
-18dB Min |
-14.4dB Min |
-13.1dB Min |
-12dB Min |
-10dB Min |
