Feature
●Compliant with IEEE 802.3at standard.
●Comply with RoHS requirements.
●Suitable for End-span PoE applications with720mA current capability.
●Operating temperature range: 0℃ to +70℃.
●Storage temperature range: -25℃ to +105℃.
Electrical Specifications @ 25℃
|
OCL: |
350uH Min. @100KHz/0.1V with 8mA DC Bias |
||
|
Hi-Pot : |
1500Vrms |
||
|
Turns Ratio: |
1CT:1CT±3% |
||
|
LK: |
0.5uH Max @100KHz/0.2V |
||
|
Cw/w |
35pF Max @100KHz/0.2V |
||
|
D.C.R: |
1.2 ohm Max |
||
|
Insertion Loss: |
1-100MHz: -1.0dB Max |
||
|
Cross Talk : |
1-100MHz: -30dB Min |
||
|
Return Loss: |
1-40MHz |
40-80MHz |
100MHz |
|
-16dB Min |
-10+20log(f/80)dB Min |
-10dB Min |
|
