Feature
●Compliant with IEEE 802.3 standard.
●Comply with ROHS requirements.
●Operating temperature range: 0℃ to +70℃.
●Storage temperature range: -25℃ to +125℃.
Electrical Specifications @ 25℃
| OCL: | 350uH Min. @100KHz/0.1V with 8mA DC Bias | ||||
| Hi-POT : | 1500Vrms | ||||
| Turn Ratio: | 1:1±3% | ||||
| LK: | 0.5uH Max @100KHz/0.2V | ||||
| Cw/w | 35PF Max @100KHz/0.2V | ||||
| D.C.R: | 1.2 ohm Max | ||||
| Insertion Loss: | 1-100MHz: -1.0dB Max | ||||
| Cross Talk : | 1-100MHz: -30dB Min | ||||
| Return Loss: | 1-30MHz | 40MHz | 50MHz | 60-80MHZ | 80-100MHZ |
| -18dB Min | -14.4dB Min | -13.1dB Min | -12dB Min | -10dB Min | |
