Feature
●Compliant with IEEE 802.3u standard.
●Comply with RoHS requirements.
●Operating temperature range: 0℃ to +70℃.
●Storage temperature range: -25℃ to +105℃.
Electrical Specifications @ 25℃
|
OCL: |
350uHMin.@100KHz/0.1V |
||||
|
Hi-POT: |
1500VAC1mA2S |
||||
|
TurnRatio: |
1:1±3% |
||||
|
LK: |
0.5uHMax@100KHz/0.2V |
||||
|
Cw/w |
28pFMax@100KHz/0.2V |
||||
|
D.C.R: |
1.1ohm Max |
||||
|
InsertionLoss: |
1-100MHz:-1.1dBMax |
||||
|
CrossTalk : |
1-100MHz:-30dBMin |
||||
|
ReturnLoss: |
1-30MHz |
40MHz |
50MHz |
60-80MHz |
80-100MHz |
|
-18dBMin |
-14.4dBMin |
-13.1dBMin |
-12dBMin |
-10dBMin |
|
