Feature
●8 mm min creepage and clearance distance between PRI&SEC
●Coplanarity:0.1[.004]Max
●Reinforced insulation for a primary circuit at a working voltage of 250Vac，
●Overvoltage category II,Pollution Degree 2，up to 2km above sea level
●Reinforced insulation for a primary circuit at a working voltage of 400Vac up to 2km above sea level
●Comply with RoHS requirements.
●Operating temperature range:-40℃ to +125℃.
Electrical Specifications @ 25℃
|
PAPAMETER |
TEST CONDITIONS |
VALUE |
|
D.C.RESISTANCE 1-3 |
@25℃ |
0.419 ohms max |
|
D.C.RESISTANCE 6-4 |
@25℃ |
0.335 ohms max |
|
INDUCTANCE 1-3 |
100KHZ 100 mVac. |
340 uH min |
|
Working Voltage |
/ |
250VAC |
|
Hi-POT 1-6 |
5000Vrms/0.5mA/ 60 sec |
6250Vrms/0.5mA/1 Sec |
|
TURNS RATIO |
6-4:1-3 |
1.1CT:1CT±2% |
