H40C06SW

Feature


●Comply with ROHS requirements.
●Operating temperature range: -40℃ to +85℃.
●Storage temperature range: -40℃ to +105℃.

    Feature


    ●Comply with ROHS requirements.
    ●Operating temperature range: -40℃ to +85℃.
    ●Storage temperature range: -40℃ to +105℃.

    Electrical Specifications @ 25℃

    OCL:

    Pri= 1.5mH Typ. @100KHz/0.05V

    OCL:

    Pri= 600uH Min @-40℃. @100KHz/0.05V

    Choke OCL:

    30uH Typ. @100KHz/0.05V

    Hi-POT :

    1500Vrms

    Turn Ratio:

    TX=1:2±3% RX=1:1±3%

    LK:

    Pri= 0.5uH Max @100KHz/0.05V

    Cw/w

    35PF Max @100KHz/0.05V

    D.C.R:

    Pri= 0.8 ohm Max

    Crosstalk:

    -60dB Typ @0.5-5MHz
